Specification
System | |
Main Processor | Industrial-Grade Processor |
Operating System | Embedded Linux |
Operating Interface | Web, Local GUI |
AI | |
AI by Recorder | Face Detection; Face Recognition; Perimeter Protection; SMD Plus |
AI by Camera | Face Detection; Face recognition; Video Metadata (Human, Motor Vehicles, and Non-Motor Vehicles); SMD Plus; Stereo Analysis; Crowd Distribution; People Counting; ANPR; Vehicle Density; Heat Map |
AcuPick AI by Camera + Recorder | Max. 16-Channel, 1 Combined Event Per Channel/s |
Perimeter Protection | |
Perimeter Performance AI by Recorder (Number of Channels) | 4 Channels, 10 IVS Rules for Each Channel |
Perimeter Performance of AI by Camera (Number of Channels) | 16 Channels |
Face Detection | |
Face Attributes | Gender; Age Group; Glasses; Expressions; Face Mask; Beard |
Face Detection Performance of AI by Recorder (Number of Channels) | 2 Channels (Up to 12 Face Images/s Each Channel) |
Face Detection Performance of AI by Camera (Number of Channels) | 16 Channels |
Face Recognition | |
Face Database Capacity | Up to 20 Face Databases with20,000 Images, with a Total Capacity of 2.5 G. Name, Gender, Birthday, Address, Credential Type, Credential No., Countries & Regions and State can be Added to Each Face Image. |
Face Recognition Performance of AI by Recorder (Number of Channels) | 1. 16 Channels FD (By Camera) + FR (By Recorder), Image Stream: 16 Face Images/s |
2. 2 Channels FD (By Recorder) + FR (By Recorder), Video Stream: 12 Face Images/s | |
Face Recognition Performance of AI by Camera (Number of Channels) | 16 Channels |
SMD Plus | |
SMD Plus by Recorder | 8-Channel: Secondary Filtering for Human and Motor Vehicle , Reducing False Alarms Caused By Leaves, Rain and Lighting Condition Change |
SMD Plus by Camera | 16 Channels |
Video Metadata | |
Metadata Performance of AI by Recorder (Number of Channels) | 8 Channels |
Human Attributes | Top Color, Top Type, Hat, Bag, Age, Gender and Umbrella |
Motor Vehicle Attributes | License Plate, Plate Color, Vehicle Body, Vehicle Model, Vehicle Logo, Calling, Seatbelt, Vehicle Interior, Vehicle Registration Location. |
Non-motor Vehicle Attributes | Vehicle Model, Vehicle Color, Number of Persons, Helmet. |
Vehicle License Plate Comparison | |
ANPR by Camera (Number of Channels) | 8 Channels |
License Plate Database Capacity | 1. Create Up to 20,000 Plate Numbers 2. Blocklist and Allowlist |
Audio and Video | |
Access Channel | 16 Channels |
Network Bandwidth | AI Disabled: 384 Mbps Incoming, 3824 Mbps Recording and384 Mbps Outgoing |
AI Enabled: 200 Mbps Incoming, 200 Mbps Recording and 200 Mbps Outgoing | |
Resolution | 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF |
Decoding Capability | AI Disabled: 2-Channel 32 MP@20 fps; 2-Channel 24 MP@20 fps; 4-Channel 16 MP@30 fps; 5-Channel 12 MP@30 fps; 8-Channel 8 MP@30 fps; 12-Channel 5 MP@30 fps; 16-Channel 4 MP@30 fps AI Enabled: 1-Channel 32 MP@20 fps; 1-Channel 24 MP@20 fps; 2-Channel 16 MP@30 fps; 4-Channel 12 MP@30 fps; 4-Channel 8 MP@30 fps; 8-Channel 5 MP@30 fps; 12-Channel 4 MP@30 fps |
Video Output | 2 VGA, 2 HDMI VGA:1920 × 1080, 1280 × 1024, 1280 × 720 HDMI:3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous video source output for HDMI1 and HDMI2 Simultaneous video source output for VGA1 and HDMI1 Simultaneous video source output for VGA2 and HDMI2 Supports 4K display |
Multi-Screen Display | Main Screen: 1/4/8/9/16 |
Sub Screen: 1/4/8/9/16 | |
Third-Party Camera Access | ONVIF; RTSP; Sony; Axis; Arecont; Pelco; Canon; Samsung |
Compression Standard | |
Video Compression | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
Audio Compression | G.711a; G.711u; PCM; G726 |
Network | |
Network Protocol | HTTP; HTTPS; TCP/IP; IPv4/IPv6; RTSP; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports Dahua IP Camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCSI |
Mobile Phone Access | iOS; Android |
Interoperability | ONVIF 22.06 (Profile T; Profile S; Profile G); CGI; SDK |
Browser | Chrome; IE; Safari; Edge; Firefox |
Recording Playback | |
Multi-Channel Playback | Up to 16 Channels |
Record Mode | General, Motion Ddetection; Intelligent; Alarm; POS |
Backup Method | USB Device and Network |
Playback Mode | Instant Playback, General Playback, Event Playback, Tag Playback, Smart Playback (Face and Motion Detection) |
Storage | |
Disk Group | Yes |
Alarm | |
General Alarm | Motion Detection; Video Tampering; Video Loss; Scene Changing, PIR Alarm, IPC External Alarm |
Anomaly Alarm | Camera Offline; Storage Error; Disk Full; IP Conflict; MAC Conflict; Login Lock; Abnormal Behavior of Fan; Cybersecurity Exception |
Intelligent Alarm | Face Detection; Face Recognition; Perimeter Protection (Intrusion and Tripwire); SMD Plus Alarms; ANPR; People Counting; Stereo Analysis; Crowd Distribution; Heat Map |
Alarm Linkage | Record; Snapshot; IPC External Alarm Output; Buzzer; Log, Preset; Email |
Port | |
Audio Input | 1-Channel RCA |
Audio Output | 2-Channel RCA |
Alarm Input | 16 Channels |
Alarm Output | 6 Channels (1-Channel 12V 1A Output) |
HDD Interface | 4 SATA Ports, Up to 16 TB. This Limit Varies Depending On the Environment Temperature. |
eSATA | 1 |
RS-232 | 1 |
RS-485 | 1 (Half-Duplex Serial Communication) |
USB | 3 (1 Front USB 2.0 Ports, 2 Rear USB 3.0 Ports) |
HDMI | 2 |
VGA | 2 |
Network Port | 1 (10/100/1000 Mbps Ethernet port, RJ-45) |
PoE Port | 16 Ports, 10/100 Mbps, IEEE 802.3 af/at, 1-8 Ports Support ePoE |
General | |
Power Supply | 100–240 VAC, 50/60 Hz |
Power Consumption | Total Output of NVR is ≤ 13 W (Without HDD) Total Output Power of PoE is 150 W, The Maximum Output Power of a Single Port is 25.5 W |
Net Weight | 4.82 kg (10.63 lb) |
Gross Weight | 7.09 kg (15.63 lb) |
Product Dimensions | 440.0 mm × 415.1 mm x 70.0 mm (17.32″ × 16.34″ × 2.76″) (W ×D × H) |
Packaging Dimensions | 530.0 mm × 500.0 mm × 210.0 mm (20.87″ × 19.69″ × 8.27″)(W × D × H) |
Operating Temperature | –10 °C to +55 °C (14 °F to +131 °F) |
Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
Operating Humidity | 10%–93% (RH) |
Installation | Rack or Desktop |
Certifications | FCC: 47 CFR FCC Part15, SubpartB, Class A CE-EMC: EN 55032: 2015+A1: 2020; EN IEC 61000-3-2: 2019+A1: 2021; EN 61000-3-3: 2013+A1: 2019+A2: 2021; EN 55035: 2017+A11: 2020; EN 50130-4: 2011+A1: 2014 CE-LVD: EN 62368-1: 2014 |
