Specification
System | |
Main Processor | Industrial Embedded Micro-Processor |
Operating System | Embedded Linux |
Operation Interface | Web; Local GUI |
Perimeter Protection by Camera | |
Performance | 16 Channels |
AI Search | Search for Pictures by Channel, Time and Event Type |
SMD Plus by Camera | |
Performance | 16 Channels |
AI Search | Search by Target Classification (Human, Vehicle) |
Video | |
Access Channel | 16 |
Network Bandwidth | 200 Mbps for Access, 200 Mbps for Storage and 96 Mbps for Forwarding |
Resolution | 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 1.3MP, 720p, D1, and More |
Decoding Capability | 8 Channels@1080p (30 fps) |
Video Output | HDMI: 3840 × 2160; 1920 × 1080; 1280 × 1024; 1280 × 720 |
VGA: 1920 × 1080; 1280 × 1024; 1280 × 720 | |
Multi-Screen Display | 1/4/8/9/16 |
Third Party Camera Access | Panasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon and More |
Compression | |
Video | Smart H.265+; Smart H.264+; H.265; H.264 |
Audio | PCM; G.711A; G.711U; G.726 |
Network | |
Network Protocol | HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (Supports Dahua IP Camera, DVR, NVS, and More); P2P |
Mobile Phone Access | Android; iOS |
Interoperability | ONVIF (Profile T/S/G); CGI; SDK |
Browser | Chrome; IE9 or Later; Firefox |
Record Playback | |
Multi-Channel Playback | 1/4/9/16 |
Record Mode | Manual; Schedule (General; MD; Alarm; MD & Alarm; Intelligent) |
Storage Method | Local HDD and Network |
Backup | USB Device |
Playback Function | 1. Play; Pause; Stop; Fast Forward; Fast Backward; Rewind; Play by Frame |
2. Full Screen; Backup (Cut/File) ; Partially Enlarge; Audio On/Off | |
Storage | |
Disk Group | Yes |
Alarm | |
General Alarm | Motion Detection; Privacy Masking; Video Loss; PIR Alarm; IPC Alarm |
Anomaly Alarm | Camera Offline; Storage Error; full Storage; IP Conflict; MAC Conflict; Login Lock; Network Security Anomaly |
Intelligent Alarm | Perimeter Protection; SMD; People Counting; Heat Map |
Alarm Linkage | Record; Snapshot; IPC External Alarm Output; Buzzer; Log; Preset; Email |
External Port | |
Audio Input | 1 Channel, RCA Connector |
Audio Output | 1 Channel, RCA Connector, Which Support Voice Intercom Output |
HDD | 2 SATA III Ports, Up to 10 TB for a Single HDD. The Maximum HDD Capacity Varies With Environment Temperature |
Alarm Input | 4 Channels |
Alarm Output | 2 Channels |
USB | 1 Front USB 2.0 Port, 1 Rear USB 3.0 Port |
HDMI | 1 |
VGA | 1 |
Network | 1 RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Port |
PoE | 16 Ports (IEEE802.3at/af) |
General Parameter | |
Power Supply | Single, 100V–240V AC, 50 Hz–60 Hz |
Power Consumption | NVR: < 13.2W (without HDD) |
PoE: Max 25.5W for single port, 130W in total | |
Net Weight | 2.6 kg (5.7 lb) (without HDD) |
Gross Weight | 4 kg (8.8 lb) (without HDD) |
Product Dimensions | 375.0 mm × 327.4 mm × 53.0 mm (14.8″ × 12.9″ × 2.1″) |
Package Dimensions | 429 mm × 360 mm × 137 mm (16.9″ × 14.2″ × 5.4″) |
Operating Temperature | -10°C to +55°C (+14°F to +131°F) |
Storage Temperature | 0°C to +40°C (+32°F to +104°F) |
Operating Humidity | 10%–93% (RH) |
Storage Humidity | 30%–85% (RH) |
Operating Altitude | 3,000 m (9,843 ft) |
