คุณลักษณะ
| Parameter | Description |
| Dimension | 115(L)x40(W)x40(H) mm |
| Button | Stainless Steel |
| Panel Material | 1.7mm 304 Stainless Steel (Wire Drawing) |
| Current | 3A/125-250VAC |
| Waterproof Grade | IP67 |
| Power | 12VDC & 24VDC |
| Output Contact | NO/NC/COM |
| Installation Mode | Hollow Door |
| Mechanical Life | 500,000 Tests |
| Operating Temperature | -10°C ~ 55°C (14°F ~ 131°F) |
| Operating Humidity | 0-95% (Non-Condensing) |
| Weight | 120 g |
