Camera |
Image Sensor | 1/2.7” 2Megapixel progressive scan CMOS |
Effective Pixels | 1920(H) ´ 1080(V) |
Scanning System | Progressive |
Electronic Shutter Speed | Auto/Manual, 1/3(4)~1/100000s |
Min. Illumination | 0.01lux/F2.0(color),0lux/F2.0 (IR on) |
S/N Ratio | More than 50dB |
Video Output | N/A |
Camera Features |
Max. IR LEDs Length | 20m |
Day/Night | Auto(ICR)/Color/B/W |
Backlight Compensation | BLC / HLC / WDR(120dB) |
White Balance | Auto/Sunny/Night/Outdoor/Customized |
Gain Control | Auto/Manual |
Noise Reduction | 3D |
Privacy Masking | Up to 4 areas |
Lens |
Focal Length | 2.8mm |
Max Aperture | F2.0 |
Focus Control | Manual |
Angle of View | H:120° |
Lens Type | Fixed lens |
Mount Type | Board-in Type |
Video |
Compression | H.264/H.264H/H.264B/MJPEG |
Resolution | 1080P(1920×1080)/1.3M(1280×960)/720P(1280×720)/D1(704×576/704×480) /CIF(352×288/352×240) |
Frame Rate | Main Stream | 1080P/720P(1 ~ 25/30fps) |
Sub Stream | D1/CIF(1 ~ 25/30fps) |
Third Stream | 720P(1-13/4fps) |
Bit Rate | H.264: 32K ~ 10Mbps |
Corridor Mode | Support |
Audio |
Compression | G.711a/ G.711u/ AAC |
Interface | Built-in Mic |
Smart Function(Optional) |
Smart detection | Tripwire |
Intrusion |
Abandoned/Missing |
Scene Change |
Audio detect |
Face detect |
Network |
Ethernet | RJ-45 (10/100Base-T) |
Wi-Fi | Wi-Fi(IEEE802.11b/g/n) |
50m(open field) |
Protocol | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour |
Compatibility | ONVIF,PSIA,CGI |
Max. User Access | 20 users |
Smart Phone | iPhone, iPad, Android, Windows Phone |
Auxiliary Interface |
Memory Slot | Micro SD Max 128GB |
RS485 | N/A |
Alarm | N/A |
PIR Sensor Range | N/A |
General |
Power Supply | DC12V |
Power Consumption | <5W |
Working Environment | -30°C~+50°C, Less than 95% RH |
Ingress Protection | IP66 |
Vandal Resistance | N/A |
Dimensions | Φ106mm×50.3mm |
Weight | 0.35kg |
