Features
◎ RS-485 communication interface
◎ Supporting WG port for anti-pass-back function
◎ TTL serial output for various application and lift control
◎ Selectable working frequencies: 125kHz/ 13.56MHz
◎ 3 control modes: M4/ M6/ M8
◎ User capacity: 1,024; Event log: 1,200
◎ 3 access modes: Card only, Card or PIN, Card and PIN
◎ Built-in Watchdog to prevent system from hanging
◎ Built-in Real Time Clock & Anti-Tamper functions
◎ Including the input of door contact, offering the alarm system of both door opening too long and being forced to open
◎ Built-in Multi-Output: Door Lock/ Alarm/ Arming/ Duress/ Security trigger signal
◎ 11 sets of Time Zone for various accessing in network
◎ 2 sets of Auto-Open Zone editable by stand-alone operation
◎ Intelligent to shift for stand-alone or networking mode while system disconnected
◎ Auto-lock of the keypad for 30 seconds after continuous failed operation by 3 times
◎ Coordinating with softwares for further application on access control, time attendance, payroll, and door/ sensor image-monitor function
◎ Flexible to integrate with other equipment
◎ 1 bi-color LED and 1 beeper for identification
